UPD7501G
View detailed images (8)

UPD7501G

SKU: UPD7501G
UPD7501G Integrated Circuit CASE: QFP64 MAKE: NEC
Product specifications
Type Integrated Circuit
Case QFP64
Manufacturer NEC
No.of Addr. Modes 5
No. of I/O Lines 12
I/O Line Types G/P Serial
Max. Inst. Len (bits) 16
Min Inst. Len (bits) 8
No. of Intrpt Lines 2
Intrpt Types Int/Ex Vec
No. of Intrpt (mask) 2
fClk Max. (Hz) 280k
fClk Min (Hz) 120k
No. of I/O Ports 3
On-Chip ROM (bytes) 1k
Nom. Supp Volt 5.0
Tech. CMOS Integrated Circuit
On-Chip RAM (Bytes) 48
Oper. Temp (°C) Min -10
Oper. Temp (°C) Max. 70
Pinout Equivalence Number 64-63
No. of Pins 64
Surface Mounted Yes/No YES
SKU 630544
