UPD7502G
View detailed images (4)

UPD7502G

SKU: UPD7502G
UPD7502G Integrated Circuit CASE: QFP MAKE: NEC
Product specifications
Type Integrated Circuit
Case QFP
Manufacturer NEC
No.of Addr. Modes 4
No. of I/O Lines 8
I/O Line Types SerialWord
Max. Inst. Len (bits) 16
Min Inst. Len (bits) 8
No. of Intrpt Lines 2
Intrpt Types Mask/Ext V
No. of Intrpt (mask) 2
fClk Max. (Hz) 410k
fClk Min (Hz) 90k
No. of I/O Ports 2
On-Chip ROM (bytes) 2k
Nom. Supp Volt 5.0
Tech. CMOS Integrated Circuit
On-Chip RAM (Bytes) 128
Oper. Temp (°C) Min 0
Oper. Temp (°C) Max. 70
Pinout Equivalence Number 64-74
Descript 1 3 and 4-bit In Port,1 4-bit Out Port
No. of Pins 64
Surface Mounted Yes/No YES
SKU 630538
