UPD78P238GC3B9
View detailed images (9)

UPD78P238GC3B9

SKU: UPD78P238GC3B9
UPD78P238GC3B9 Integrated Circuit CASE: QFP80 MAKE: NEC
Product specifications
Type Integrated Circuit
Case QFP80
Manufacturer NEC
No. of I/O Lines 76
I/O Line Types Byte/GenP
Max. Inst. Len (bits) 40
Min Inst. Len (bits) 8
No. of Intrpt Lines 7
No. of Intrpt (NMI) 1
Intrpt Types Prty/Softw
No. of Intrpt (mask) 18
fClk Max. (Hz) 12M
No. of I/O Ports 12
On-Chip ROM (bytes) 32k
Nom. Supp Volt 5.0
Tech. CMOS Integrated Circuit
On-Chip RAM (Bytes) 640
Oper. Temp (°C) Min -40
Oper. Temp (°C) Max. 85
Pinout Equivalence Number 80-74
Descript OTP ROM,4 Timers,8-Input ADC,2 Out DAC
No. of Pins 80
Surface Mounted Yes/No YES
SKU 1136995
