ZTX504
View detailed images (4)

ZTX504

SKU: ZTX504
ZTX504 Transistor Silicon PNP CASE: TO92S MAKE: Zetex
Price:
£5.75 Inc. VAT (£4.79 Ex. VAT)
£5.75 Inc. VAT (£4.79 Ex. VAT)
Qty
  • 10 pieces in 1-2 Days
  • More pieces shipped in 14 days
?
Product specifications
Type Transistor Silicon PNP
Case TO92S
Manufacturer Zetex
Vbr CBO 70
Vbr CEO 70
Max. PD (W) 300m
C(ob) (F) 6.0p
Derate (Amb) (W/°C) 3.0m
hfe 50
Ic Max. (A) 500m
Icbo Max. @Vcb Max. (A) 200n
Polarity PNP
Trans. Freq (Hz) Min. 150M
@VCE (test) (V) 6.0
Oper. Temp (°C) Max. 175
@Ic (A) 10m
Pinout Equivalence Number 3-12
Surface Mounted Yes/No NO
Maximum Collector Power Dissipation (Pc) 0.3 W
Maximum Collector-Base Voltage |Vcb| 70 V
Maximum Collector-Emitter Voltage |Vce| 70 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 0.5 A
Max. Operating Junction Temperature (Tj) 125 °C
Collector Capacitance (Cc) 6 pF
Transition Frequency (ft): 150 MHz
Forward Current Transfer Ratio (hFE), MIN 50
SKU 116936
