PZT2222
View detailed images (8)

PZT2222

SKU: PZT2222
PZT2222 Transistor Silicon NPN CASE: SOT223 MAKE: Fairchild Semiconductor
Price:
£5.75 Inc. VAT (£4.79 Ex. VAT)
£5.75 Inc. VAT (£4.79 Ex. VAT)
Qty
Product specifications
Equivalent PZT2222A
Type Transistor Silicon NPN
Case SOT223
Manufacturer Fairchild Semiconductor
Vbr CBO 60
Vbr CEO 30
Max. PD (W) 1.5
t(f) Max. (S) 60n
Max. hFE 300
Min hFE 100
Ic Max. (A) 600m
@Ic (test) (A) 150m
Icbo Max. @Vcb Max. (A) 10n
Polarity NPN
Tr Max. (s) 25n
Trans. Freq (Hz) Min. 250M
Oper. Temp (°C) Max. 150
@VCE (V) 10
Pinout Equivalence Number N/A
Surface Mounted Yes/No YES
Maximum Collector Power Dissipation (Pc) 1.3 W
Maximum Collector-Base Voltage |Vcb| 60 V
Maximum Collector-Emitter Voltage |Vce| 30 V
Maximum Emitter-Base Voltage |Veb| 5 V
Maximum Collector Current |Ic max| 0.6 A
Max. Operating Junction Temperature (Tj) 150 °C
Collector Capacitance (Cc) 8 pF
Transition Frequency (ft): 200 MHz
Forward Current Transfer Ratio (hFE), MIN 100
SMD Transistor Code ZT2222
SKU 1282309
